FM 4-20.119: Airdrop of Supplies and Equipment: Rigging 105-Millimeter Howitzers

Official US Army Field Manual in Acrobat PDF file format.

This manual shows how to rig the M102, M119, and M101A1 105-millimeter howitzers for low-velocity airdrop from a C-130 or C-17 aircraft. The manual includes procedures and equipment for rigging the M102 and M119 105-millimeter howitzer with the 1 ¼-ton High Mobility Multipurpose Wheeled Vehicle (HMMWV) truck as the prime mover on a 32-foot, type V airdrop platform for low-velocity airdrop from a C-130 or C-17 aircraft. In addition, procedures are given for rigging two M119 105-millimeter howitzers on a single platform with two different ammunition loads and with two 81-millimeter mortars for a low-velocity airdrop from C-130 or C-17 aircraft. The manual is designed for use by all parachute riggers.

File download size: 40.4 MB
